Price
$741.00
Specifications
Model Number
HTR-133
Materials
SS, SS Bellows, Anodized Aluminum
RoHS Compliant
Yes
Max. Bake Temperature
250ºC
Max. Vacuum Level
1x10E-10 Torr
Axial Load
6 lb. maximum
Lateral Load
10 lb. maximum
Resolution - Rotary Scale
5° (Degrees)
Torque
250 in-oz maximum
Speed
1000 RPM
Outline Drawing (DEPRECATED)
1021003D Model - Zipped STEP file (DEPRECATED)
102100 AGP.ZIPeDrawing (DEPRECATED)
102100.11.EPRTXCart Product Code
102100
stock level (qty)
955
Images
Variations
Product Category
Additional Categories
Detailed Images
Outline Drawing
102100.pdf (357.66 KB)
102100.11.pdf (353.99 KB)
102100.12_1.pdf (410.78 KB)
102100.21_1.pdf (329.58 KB)
102100.31_1.pdf (369.98 KB)
eDrawing
102100.eprt (251.33 KB)
102100-113086.eprt (260.71 KB)
102100.11.eprt (349.54 KB)
102100.12_1.eprt (469.3 KB)
102100.21_1.eprt (322.08 KB)
102100.31_1.eprt (317.92 KB)
3D Model - Zipped STEP file
102100.zip (1.28 MB)
102100-113086.zip (1.28 MB)
102100.11.zip (1.51 MB)
102100.12_1.zip (2.07 MB)
102100.21_1.zip (1.45 MB)
102100.31_1.zip (1.53 MB)
XCart Product ID
16439
